1 Topic by brutaldeath (edited by brutaldeath 2024-06-21 15:36:46)

Topic: Arduino Portenta Machine Control

Hello,
I share to you the .elmt for the Arduino Portenta Machine Control

Hope it's usefull

Do not hesitate to answer for adjustement nomicons/wink

Maybe the draw it's too small ? I don't know

Post's attachments

Attachment icon portenta_machine_controler.elmt 29.79 kb, 46 downloads since 2024-06-21

2 Reply by plc-user (edited by plc-user 2024-06-21 21:35:37)

Re: Arduino Portenta Machine Control

Hello brutaldeath!

brutaldeath wrote:

Do not hesitate to answer for adjustement nomicons/wink

In my opinion:
Elements with so many terminals should be divided into several function groups and then added to the collection as master/slave elements.
For another case, I once suggested something like this from the appendix. The slave components are only roughly sketched and still need to be reworked, but that's roughly what I mean.
The manufacturer, designation and label for the slaves are dynamic texts that are filled from master-info, when connected.

[Edited]
And when it comes to automatic generation of cable-plans (https://qelectrotech.org/forum/viewtopic.php?id=2764):
The terminals need to have names.

You asked for feedback!  nomicons/wink

Best regards
  plc-user

Post's attachments

Bildschirmfoto_Master-Slave.png, 95.73 kb, 783 x 501
Bildschirmfoto_Master-Slave.png 95.73 kb, 32 downloads since 2024-06-21
